OSTA-05
額定電流 / Corresponding current 20A、25A、30A  | 防水結(jié)構(gòu) / Waterproof Structure 灌封膠 / Potting sealant  |
額定電壓 / Rated voltage 1500V  | 連接方式 / Connection Method 焊 接 / Soldering  |
工作電壓 / Max working voltage 100V  | 絕緣材料 / Insulation Material PPE+PS  |
使用溫度 / Ambient temperature -40~+85℃  | 接觸材料 / Contact Materia 銅鍍錫 / Copper tin plating  |
防水等級 / Degree of protection IP65/IP68 (1m,1h)  | 灌膠量 / Volume Of Silicon Gel Up to 9mm-7.0g  |
保護等級 / Pollution degree class A  | 連接線規(guī)格 / Connecting capacity 1x4mm2、 12AWG  |
防火等級 / Flame class UL94-V0 5VA  | 可選連接器/Optional Connector CD2, EVO2,MC4  |
